  • BLC3303

    BLC3303

    BLC3303 – Fill only – Fill w/ Burner OFF-ON/LOCKOUT – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Fill and Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level and a FILL button to initiate the FILL command for 30 seconds. If the burner is OFF for 90 seconds it is locked out and can only be restarted by pressing the “RESTART” button. Drives Power Relays for Burner and Fill Operation.

    See the Brochure for models, for detailed drawings and options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: Controls operate on 220VAC, 110VAC or 24VAC and has Relay Contacts rated 30AMPS at 250Volts & Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Installation: Boiler Low alarm, Boiler level control. All of Waterline Controls models easily and quickly integrate with existing building automation systems. This allows the operator to continuously monitor and
  • BLC3201

    BLC3201

    BLC3201 – Burner Off-On – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BMS for measuring Burner “ON/OFF” times and to indicate Power Loss. Drives a Power Relay for Burner.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3302

    BLC3302

    BLC3302 – Fill w/ Burner Off-ON – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Fill and Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level and a FILL button to initiate the FILL command for 30 seconds. Drives Power Relays for Burner and Fill Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Installation: Boiler Low alarm, Boiler level control. All of Waterline Controls models easily and quickly integrate with existing building automation systems. This allows the operator to continuously monitor and
    Boiler Installation: Boiler Low alarm, Boiler level control. All of Waterline Controls models easily and quickly integrate with existing building automation systems. This allows the operator to continuously monitor and
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3204

    BLC3204

    BLC3204 – Burner OFF-ON/DELAYS – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level. Delays of 15 seconds for OFF and 30 seconds for ON are active. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3205

    BLC3205

    BLC3205 – Burner Off-On/DELAYS AND AUTO TEST – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level. Delays of 15 seconds for OFF and 30 seconds for ON are active. Every 10 minutes the Burner is turned off for 90 seconds and tested for water level. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3206

    BLC3206

    BLC3206 – Burner Off-On/DELAYS AND AUTO TEST – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level. Delays of 15 seconds for OFF and 30 seconds for ON are active. Every 20 minutes the Burner is turned off for 60 seconds and tested for water level. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3207

    BLC3207

    BLC3207 – Burner Off-On/DELAYS AND AUTO TEST – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level. Delays of 15 seconds for OFF and 30 seconds for ON are active. Every 15 minutes the Burner is turned off for 60 seconds and tested for water level. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3208

    BLC3208

    BLC3208 – Fill Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Fill “ON/OFF” times and to indicate Power Loss. A FILL button to initiate the FILL command for 30 seconds. Drives Power Relays for Fill Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3209

    BLC3209

    BLC3209 – Burner OFF-ON/lockout Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss and a lockout condition. If the burner is OFF for 30 seconds it is locked out and can only be restarted by pressing the “RESTART” button. Drives a Power Relay for Burner operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3210

    BLC3210

    BLC3210 – Burner OFF-ON/lockout Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss and a lockout condition. A test button to force the Burner OFF without needing to lower the water level is provided. If the burner is OFF for 30 seconds it is locked out and can only be restarted by pressing the “RESTART” button. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3211

    BLC3211

    BLC3211 – Burner Off- On – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level is provided. Drives a Power Relay for Burner.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3212

    BLC3212

    BLC3212 – Burner OFF-ON/lockout Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss and a lockout condition. A test button to force the Burner OFF without needing to lower the water level is provided. If the burner is OFF for 30 seconds it is locked out and can only be restarted by pressing the “RESTART” button. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3213

    BLC3213

    BLC3213 – Burner Off-On/DELAYS AND AUTO TEST – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Burner “ON/OFF” times and to indicate Power Loss. A test button to force the Burner OFF without needing to lower the water level. Delays of 15 seconds for OFF and 30 seconds for ON are active. Every 20 minutes the Burner is turned off for 90 seconds and tested for water level. Drives a Power Relay for Burner Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3214

    BLC3214

    BLC3214 – Fill w/ Fill Off-ON – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Fill “ON/OFF” times and to indicate Power Loss. A FILL button to initiate the FILL command for 30 seconds. Drives a Power Relay for Fill Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • BLC3215

    BLC3215

    BLC3215 – Electronic Water Level Control. Complete Kit Includes two Sensors, 50 ft. Sensor Wire & Controller. Dry contacts to BAS for measuring Drain “ON/OFF” times. Maintains level between two probes (maintains water level at the lowest probe). Drives a Power Relay for the Drain Operation.

    See the Brochure for models, detailed drawings & Options

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Option A; use the “spark plug type sensors” or Option B; for deionized or demineralized water we can supply a Stainless Steel Float switch for the holding tank.  We will need the Sensor Appendix filled out and returned in this case.  In both applications the sensors should never need to be replaced because of the way we power the sensor system.

    Electrical: This unit can be supplied with 220VAC, 110VAC or 24VAC and it has Relay Contacts rated 30AMPS at 250Volts and Dry Contacts rated 0.5AMPS at 60Volts.
    The Sensor wire system is Intrinsically Safe.
    Boiler Liquid level controls: Boiler valve,boiler installation,boiler control, conductivity sensor,water level switch
  • WLC-3000-Fill Only

    WLC-3000-Fill Only

    Fill Only With Diagnostics-Complete Kit Includes Sensor With 50 ft. Sensor Wire, The Controller, and Mounting Assembly.
    Fill Only | SINGLE-CONTACT POINT | Custom Sensors lengths available upon request | 4-wire Dry contacts to BMS for measuring Fill “ON” time and fault conditions.
    Operates any 110VAC valve. (Not supplied in this kit (See Options Section for valves)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Liquid level control: Water level control for cooling towers, Boilers and building fire water holding tanks.
  • Model: WLC-WS3000

    Model: WLC-WS3000

    Fill Only With Diagnostics-Complete Kit Includes Sensor With 50 ft. Sensor Wire, The Controller, and Mounting Assembly.
    Fill Only | SINGLE-CONTACT POINT | Custom Sensors lengths available upon request | 4-wire Dry contacts to BMS for measuring Fill “ON” time and fault conditions.
    Operates any 5HP pump or less. (Not supplied in this kit)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter up to 12 feet long.

    Electrical: Controls operate at 5HP at 220VAC Internal Relay Contacts rated 40AMPS at 250Volts Dry Contacts, if used, are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Liquid level control: Water level control for cooling towers, Boilers and building fire water holding tanks.
    Water level control: Water level controls for well water holding tanks
  • Jefferson Valves-Slow Closing

    Jefferson Valves-Slow Closing

    The Valves we provide are all considered Slow Closing Valves.  They are all Brass and use a NEMA4X Electrical connection.



    Valve Sizes:  We Offer 3/4”, 1″, 1-1/4″, 1-1/2″ & 2″ For indoor and outdoor use.

    3/4″ JEFF01-110 or 220

    1″ JEFF02-110 or 220

    1-1/4″ JEFF03-110 or 220

    1-1/2″ JEFF04-110 or 220

    2″ JEFF01-110 or 220

    Electrical: 110VAC - 50/60Hz these are rated 0.9 AMPS at a Peak and 0.6AMPS Continuos.
                     220VAC - 50/60Hz these are rated 0.45 AMPS at a Peak and 0.3AMPS Continuos.
    See the Chart below for flow rates
    Liquid level control: Water level control for cooling towers, Boilers and building fire water holding tanks.
    Slow Closing Solenoid valves: Valves for liquid level controls and Water level control for cooling towers, Boilers and building fire water holding tanks.
  • ASCO/REDHAT Valves-Slow Closing

    ASCO/REDHAT Valves-Slow Closing

    The Valves we provide are all considered Slow Closing Valves.  They are all Brass and use a NEMA4X Electrical connection.



    Valve Sizes:  We Offer 3/4”, 1″, 1-1/4″, 1-1/2″ & 2″ For indoor and outdoor use.

    3/4″ ASCO01-110 or 220

    1″  ASCO02-110 or 220

    1-1/4″  ASCO03-110 or 220

    1-1/2″  ASCO04-110 or 220

    2″  ASCO05-110 or 220

    Electrical: 110VAC - 50/60Hz these are rated 0.9 AMPS at a Peak and 0.6AMPS Continuos.

                     220VAC - 50/60Hz these are rated 0.45 AMPS at a Peak and 0.3AMPS Continuos.
    See the Chart below for flow rates
    Liquid level control: Water level control for cooling towers, Boilers and building fire water holding tanks.
    Slow Closing valves for Liquid level control: Valves for liquid level and Water level control for cooling towers, Boilers and building fire water holding tanks.
  • SWS3000-Fill Only

    SWS3000-Fill Only

    Fill Only With Diagnostics-Complete Kit Includes Sensor With 50 ft. Sensor Wire and The Controller.
    Fill Only | SINGLE-CONTACT POINT | Custom Sensors lengths available upon request | 4-wire Dry contacts to Building Management System for measuring Fill “ON” time and fault conditions.
    Directly Operates any 110VAC valve. (Not supplied in this kit (See Options Section for valves)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Liquid level control: Water level control for cooling towers, Boilers and building fire water holding tanks.
    Swimming Pool or Fountain water level control: Water level control for Commercial Pools and Fountains
  • WLC-4000-Fill W/High Alarm

    WLC-4000-Fill W/High Alarm

    WLC-4000 – Fill w/ High Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BAS for measuring Fill “ON” time, High Water Alarm and fault conditions. () Operates any 110VAC valve & 110VAC audible alarm (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Liquid level controls & water level controls: Water level controls for cooling towers, Boilers and holding tanks. Each Model is different
    Liquid level controls & water level controls: Water level controls for cooling towers, Boilers and holding tanks. Each Model is different
  • SWS4000

    SWS4000

    SWS4000 – Fill w/ High Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire & Controller | Fill w/ High Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BAS for measuring Fill “ON” time, High Water Alarm and fault conditions. () Operates any 110VAC valve; and/or 110VAC audible alarm (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Liquid level controls & water level controls: Water level controls for cooling towers, Boilers and holding tanks. Each Model is different
    Liquid level controls & water level controls: Water level controls for cooling towers, Boilers and holding tanks. Each Model is different
  • WLC-4500-Fill W/ Low Alarm

    WLC-4500-Fill W/ Low Alarm

    WLC-4500 – Fill w/ Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ Low Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BMS for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates any 110VAC valve & 110VAC audible alarm (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Fill With Low alarm Water level controls: Never replace a Water level controller again.
  • WLC-WS4500

    WLC-WS4500

    WLC-WS4500 – Fill w/ Low Alarm – Electronic Water Level Control | Kit Includes Controller Only | Fill w/ Low Alarm | THREE-CONTACT POINT SYSTEM | 6-wire Dry contacts to BMS for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates any 5HP pump or less. (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: We will need the Sensor Appendix filled out and returned in this case.

    Electrical: Controls operate at 0.5AMPS at 110VAC.  Internal Relay Contacts are rated for 5HP(40AMPS at 220VAC) for the fill and 30AMPS at 250Volts91HP for the Low Cut off). The Dry Contacts for BMS(Building Management System) are rated 0.5AMPS at 60Volts.
    The Sensor wire system and sensors are Intrinsically Safe.
    Boiler installation: This is the best product for the best price and included building automation connections so the unit can be seen remotely-no more hassles!
    Water Well Holding tank installation: This is the best product for the best price and included building management connections so the unit can be seen remotely-no more hassles!
  • Model: WLC-WST4500

    Model: WLC-WST4500

    WLC-WST4500 – Fill w/ Low Alarm – Electronic Water Level Control | Complete Kit Includes adjustable Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ Low Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to Building Management System (BMS) for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates an internal 24vac transformer to power a 24vac valve (Not supplied in this kit.) and 1 high voltage relay for the low alarm.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter up 12 feet long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Fire Protection tank Level Control with Low Alarm: This controller has silencer alarms fill switches and complete connections to Building Automation System so you can electronically see what the tank is doing.
    Water level controls for fire protection tanks: There are a variety of units for this application. We make the most advanced liquid level controls for this application then any other product in the market. It is provided as a kit
  • SWS4500

    SWS4500

    SWS4500 – Fill w/ Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire & Controller| Fill w/ Low Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BMS for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates any 110VAC valve; and/or 110VAC audible alarm (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Fill With Low alarm Water level controls: Never replace a Water level controller again.
  • WLC-5000-Fill W/High & Low Alarm

    WLC-5000-Fill W/High & Low Alarm

    WLC-5000 – Fill w/ High & Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High Alarm | THREE-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 8-wire Dry contacts to BMS for measuring Fill “ON” time, Low Water Alarm, High Water Alarm and fault conditions. () Operates any 110VAC valve & 110VAC audible alarm (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Cooling Tower Water Level Control with Basin Heater low alarm control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Audio Alarm-Internal

    Audio Alarm-Internal

    AUDIO ALARM-110db

    MOUNTS INSIDE THE WLC SERIES CONTROLS  It is included in some model applications.  These alarms are NEMA4X.  We can wire them into the Low Alarm, the High Alarm or both.  In all cases we use a Silencer Switch so it can be silenced whenever necessary.


  • External Static Pipe

    External Static Pipe

    All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

    For most applications we typically use a 3″ Sensor head which fits into any 3″ Slip Style fitting.  Regardless of which controls are used this sensor will hold all the sensor tips for all the models.  This housing and the sensor lengths can be customized for your application.  We have developed custom probes and assemblies for some OEM Customers under Private Label brands.

    Standard Sensor assembly: 3” diameter and approximately 20” long.



    Part Number is EXT

    e.g. WLC-5000-110-EXT-50  Is a 5000 Controller with an external static pipe sensor and a 50 ft wire lead on the sensor.




    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Vanstone Flange

    Vanstone Flange

    All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

    We do make 2-1/2″ Vanstone flange sensors that are direct replacements for Evapco Cooling tower level controls (see this page for the technical details).  We can use any size vanstone flange to build a sensor into without any issues.  Let us know what you need for your application and we can help you get the right parts.  You can use this Sensor Appendix to get the correct length sensor tips needed.

    PART NUMBERS for Sensor Tip Extensions

    EXT3FT is a 3 ft extension kit with both ends threaded (this allows for other rods to be added)

    EXT4FT is a 4 ft extension kit with both ends threaded (this allows for other rods to be added)

    EXT5FT is a 5ft extension kit with both ends threaded (this allows for other rods to be added)

    AXT3FT is a 3 ft extension kit with one ends threaded (these are the finished ends)

    AXT4FT is a 4 ft extension kit with one ends threaded (these are the finished ends)

    AXT5FT is a 5ft extension kit with one ends threaded (these are the finished ends)

    Each sensor tip comes with the part necessary to assemble them together to the Sensor head.
    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Pressure Switch

    Pressure Switch

    All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

    This Pressure switch is durable and long lasting.  It operates on a low differential pressure.

    This can be used in place of the Standard Sensor assembly when ever it is not possible to use.



    Part Number is PR01

    e.g. WLC-5000-110-PR01  Is a 5000 Controller with a Pressure Switch Sensor.  The advantage is in using the controls with this switch are all the outputs the controls offer to high voltage relays and BAS dry contacts for electronically “seeing the functionality of the switch.




    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Dual Sensor Probe Assembly

    Dual Sensor Probe Assembly

    All the Sensors we produce are Intrinsically Safe.

    All WaterLine Controls WLC models can be fitted with a secondary PCB to operate two different sensor probe assemblies.  Now two probes can be mounted into two different environments provided there is an equalization line between them.  The controller can operate the same device(s) and will need a properly valved system so it can share either the same Fill valve or pump when it decides to operate.  The sensor are which ever style you choose.  The switch is done with a single switch located on the WaterLine Controls panel. No other parts are needed.

    Standard Sensor assembly: 3” diameter and approximately 20” long.



    Part Number is: Dual

    e.g. WLC-5000-110-DUAL-50/50  Is a 5000 Controller with a dual static pipe and sensor and a 50 ft wire lead on each of the sensors. Includes the controls and installation set-up for both sensors and two sensors.




    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Internal Static Pipe-Standard

    Internal Static Pipe-Standard

    All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

    This is the standard sensor that comes with every kit.  For most applications we typically use a 3″ this Sensor head which fits into any 3″ Slip Style fitting.  Regardless of which controls are used this sensor will hold all the sensor tips for all the models.  The sensor tip lengths are standard lengths but can be modified as needed for your application by submitting this Sensor Appendix.  We make custom lengths and develop part numbers for some OEMs under Private Labels.

    Standard Sensor assembly: 3” diameter and approximately 20” long.



    Part Number is STD

    e.g. WLC-5000-110-EXT-50  Is a 5000 Controller with an external static pipe sensor and a 50 ft wire lead on the sensor.




    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Custom Sensor Length Extensions

    Custom Sensor Length Extensions

    All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

    For most applications we typically use a 3″ this Sensor head which fits into any 3″ Slip Style fitting.  Regardless of which controls are used this sensor will hold all the sensor tips for all the models.  The sensor tip lengths are standard lengths but can be modified as needed for your application by submitting this Sensor Appendix with your request for quote or your order.  We make several different types of sensor heads for your application.  The Sensor can be cut in the field as needed to fit your application.

    Standard Sensor assembly: 3” diameter and approximately 20” long.



    Part Number is STD for the standard lengths

    PART NUMBERS for Sensor Tip Extensions

    EXT3FT is a 3 ft extension kit with both ends threaded (this allows for other rods to be added)

    EXT4FT is a 4 ft extension kit with both ends threaded (this allows for other rods to be added)

    EXT5FT is a 5ft extension kit with both ends threaded (this allows for other rods to be added)

    PART NUMBERS for Sensor Tips

    AXT3FT is a 3 ft extension kit with one ends threaded (these are the finished ends)

    AXT4FT is a 4 ft extension kit with one ends threaded (these are the finished ends)

    AXT5FT is a 5ft extension kit with one ends threaded (these are the finished ends)

    Each sensor tip comes with the part necessary to assemble them together to the Sensor head.  These sensor can be cut to length in the field.

    e.g. WLC-5000-110-EXT-50  Is a 5000 Controller with an external static pipe sensor and a 50 ft wire lead on the sensor.




    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Float Switch Controls

    These are low cost controls for any Float Switch operation.  This control comes in four different configurations: Single Float pump up or pump down, Two float pump up or pump down, single float pump up or down with a second float for a low alarm or high alarm and a pump up or down using two floats with a high or low alarm.



    At this point we do not supply the float switches.  We are supply these controls so the voltage in the water or wet area meets the UL requirements not to exceed 24VAC.  These will always operate less the 24VAC through the float switches.  The enclosure is a NEMA6R and ideal for wet applications.  Ask your contractor how he plans to operate the floats so you know he is using some sort of low voltage system.  While we prefer the low voltage electronic sensing system we developed we realize that it may not always fit into the budget and has more features and functions than are needed for your application.

    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Float Switches: float switch, float switches, Float switch control
  • FPT-50

    FPT-50

    FPT-50 – FPT-50 – Service Level Control w/ High & Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Dry contacts to BMS for measuring Fill “ON” time, Low Water Alarm, High Water Alarm and fault conditions | Operates 110VAC Solenoid Valve & Two 110VAC 95db Audible Alarm w/ Silencer Switches Installed in the Panel.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Fire Protection Water Level Control: Fire protection tank controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • SWS5000

    SWS5000

    SWS5000 – Fill w/ High & Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire & Controller| Fill w/ High Alarm | THREE-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 8-wire Dry contacts to BMS for measuring Fill “ON” time, Low Water Alarm, High Water Alarm and fault conditions. () Operates any 110VAC valve & 110VAC audible alarm (Not supplied in this kit.)

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.

    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Water Feature Water Level Control: Swimming Pool Water level control system
  • WLC-6000-Liquid level Fill/W High&Low Alarms and Low-Low Heater Cut Off

    WLC-6000-Liquid level Fill/W High&Low Alarms and Low-Low Heater Cut Off

    WLC-6000 – Fill w/ High & Low Alarms and a Low-Low Basin Heater Cut-off – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High & Low Alarm and Low-Low Basin Heater Cut-off| FOUR-CONTACT POINT SYSTEM | Custom Sensors lengths and wire lengths available upon request | 10-wire Dry contacts to BMS for measuring Fill “ON” time, High Water Alarm and fault conditions.- liquid level fill w high and low alarm & heater cut off

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Cooling Tower Water Level Control with alarms: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Cooling Tower Water Level Control with Basin Heater low alarm control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • SWS6000

    SWS6000

    SWS6000 – Fill w/ High & Low Alarms and a Low-Low Basin Heater Cut-off – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire & Controller| Fill w/ High & Low Alarm and Low-Low Basin Heater Cut-off| FOUR-CONTACT POINT SYSTEM | Custom Sensors lengths and wire lengths available upon request | 10-wire Dry contacts to BMS for measuring Fill “ON” time, High Water Alarm and fault conditions.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Commercial Water Feature: Water level management for Commercial Water Features
    Cooling Tower Water Level Control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
  • Model: WLC-7000

    Model: WLC-7000

    PUMP DOWN OR DRAIN ONLY SYSTEM – WITH INTERNAL DIAGNOSTIC TEST SYSTEM – WaterLine Controls™ Model WLC-7000.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: Pressure Switch or float switch or WaterLine Controls Standard 3” diameter Sensor Head Assemblies.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BMS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
  • Model: WLC-8000

    Model: WLC-8000

    PUMP DOWN OR SINGLE DRAIN WITH HIGH LEVEL SET POINT – WITH INTERNAL DIAGNOSTIC TEST SYSTEM – WaterLine Controls™ Model WLC-8000.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: 3” diameter and 20” long.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
  • Model: WLC-9000

    Model: WLC-9000

    DUAL PUMP DOWN SYSTEM OR DUAL DRAIN WITH HIGH LEVEL SET POINT – WITH INTERNAL DIAGNOSTIC TEST SYSTEM – WaterLine Controls™ Model WLC-9000.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: The standard Sensor is 3” diameter and 20” long.  However, any type of sensor can be used including pressure switches and float switches.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
  • Model: WLC-9100

    Model: WLC-9100

    LEAD-LAG CONTROLLER DUAL PUMP DOWN SYSTEM OR DUAL DRAIN WITH ALTERNATING PUMPS SYSTEM AND HIGH LEVEL SET POINT – WITH INTERNAL DIAGNOSTIC TEST SYSTEM – WaterLine Controls™ Model WLC-9100.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

    Sensor assembly: The standard Sensor is 3” diameter and 20” long.  However, any type of sensor can be used including pressure switches and float switches.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe.
    Lead Lag Dual Drain Controller: Lead-lag pump system dual drain high alarm
  • Water Level Indicator

    Water Level Indicator

    CheckPoint can be used in place of any Ultrasound Level Indicator, especially in water where there can sometimes be technical issues with the Ultrasound technology. CheckPoint easily integrates into any Building Automation System (BMS) using 0-20mA input as a function of level in the environment. CheckPoint can be made in any length needed for your application. CheckPoint is the latest development from WaterLine Controls. It is a digital Liquid Level Indicator, Water Level Indicator and Water Level Indicator For Tank level indicators. It is not intended to be a level controller.  It’s design and technology is designed to provide a level indication inside and environment.  It is plus or minus 5%-10% accurate.

    Liquid Level Indicator: ELECTRONIC LEVEL INDICATOR. CHECKPOINT MODEL Order the length you need for your application 0-20MA Output.
    Liquid Level Indicator: ELECTRONIC LEVEL INDICATOR. CHECKPOINT MODEL Order the length you need for your application 0-20MA Output.
    Water Level Indicator: Water Level Indicator
  • WLC-6100T-Fill W/High&Low Alarms and Basin Heater Controls

    WLC-6100T-Fill W/High&Low Alarms and Basin Heater Controls

    WLC-6100T – Fill w/ High & Low Alarms and a Low-Low Basin Heater Cut-off and Basin Heater Controls – Electronic Water Level Control | Complete Kit Includes Level Sensors & Temperature Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High & Low Alarm and Low-Low Basin Heater Cut-off & Heater Control| FOUR-CONTACT POINT SYSTEM WITH ONE TEMPERATURE SENSOR | Custom Sensors lengths and wire lengths available upon request | 10-wire Dry contacts to BAS for measuring Fill “ON” time, High Water Alarm, Low Water Alarm, Heater “ON” and fault conditions.

    Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.
    Sensor assembly: 3” diameter and 20” long.
    Electrical: Controls operate at 0.5AMPS at 110VAC Internal Relay Contacts rated 30AMPS at 250Volts Dry Contacts for BAS are rated 0.5AMPS at 60Volts.
    The Sensor is Intrinsically Safe. The heater control relay is designed to be a pilot relay for operating a 110VAC coil on a contractor properly sized for the heater.

    The temperature probe is built into the water level sensor and is to be mounted below the minimum water level of the tank (see the accompanying figure). It is also to be mounted at least 24 inches from the tank heater.

    Cooling Tower water level control with Basin Heater low alarm control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Cooling Tower water level control with Basin Heater low alarm control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
    Cooling Tower water level control with Basin Heater low alarm control: cooling tower, cooling tower water level controls, float switch, float switches, level sensor, level sensors, level control, water level controller, liquid level sensor, liquid level sensors
