WLC-BLC3000 – Fill only – Electronic Water Level Control | Kit Includes Controller only | Fill only | ONE-CONTACT POINT SYSTEM | 4-wire Dry contacts to Building Management System(BMS) for measuring Fill “ON” time and fault conditions. () Operates any 110VAC valve and has an option for 110VAC audible alarm (Not supplied in this kit.)

See the BLC4500 for a detailed drawing

Enclosure: 8-3/4” X 10-1/2” X 6” including the hinge and the latch. For indoor and outdoor use.

Fill Only With Diagnostics-Complete Kit Includes Sensor With 50 ft. Sensor Wire, The Controller, and Mounting Assembly.
Fill Only | SINGLE-CONTACT POINT | Custom Sensors lengths available upon request | 4-wire Dry contacts to BAS for measuring Fill “ON” time and fault conditions.
Operates any 110VAC valve. (Not supplied in this kit (See Options Section for valves)

The Valves we provide are all considered Slow Closing Valves.  They are all Brass and use a NEMA4X Electrical connection.

Valve Sizes:  We Offer 3/4”, 1″, 1-1/4″, 1-1/2″ & 2″ For indoor and outdoor use.

3/4″ JEFF01-110 or 220

1″ JEFF02-110 or 220

1-1/4″ JEFF03-110 or 220

1-1/2″ JEFF04-110 or 220

2″ JEFF01-110 or 220

The Valves we provide are all considered Slow Closing Valves.  They are all Brass and use a NEMA4X Electrical connection.

Valve Sizes:  We Offer 3/4”, 1″, 1-1/4″, 1-1/2″ & 2″ For indoor and outdoor use.

3/4″ ASCO01-110 or 220

1″  ASCO02-110 or 220

1-1/4″  ASCO03-110 or 220

1-1/2″  ASCO04-110 or 220

2″  ASCO05-110 or 220

Electrical: 110VAC - 50/60Hz these are rated 0.9 AMPS at a Peak and 0.6AMPS Continuos.

WLC-4500 – Fill w/ Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ Low Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BAS for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates any 110VAC valve & 110VAC audible alarm (Not supplied in this kit.)

WLC-WS4500 – Fill w/ Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ Low Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BAS for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates on 220VAC & and any 220VAC 5HP pump for the fill and 1.5HP pump for the low alarm. (Not supplied in this kit.)

WLC-FPT4500 – Fill w/ Low Alarm – Electronic Water Level Control | Complete Kit Includes adjustable Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ Low Alarm | TWO-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 6-wire Dry contacts to BAS for measuring Fill “ON” time, Low Water Alarm and fault conditions. () Operates any 110VAC valve (Not supplied in this kit.) | Includes 110db audible alarm and 2 high voltage relays for the fill and the low alarm.

WLC-5000 – Fill w/ High & Low Alarm – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High Alarm | THREE-CONTACT POINT SYSTEM | Custom Sensors lengths available upon request | 8-wire Dry contacts to BAS for measuring Fill “ON” time, Low Water Alarm, High Water Alarm and fault conditions. () Operates any 110VAC valve & 110VAC audible alarm (Not supplied in this kit.)

All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

For most applications we typically use a 3″ Sensor head which fits into any 3″ Slip Style fitting.  Regardless of which controls are used this sensor will hold all the sensor tips for all the models.  This housing and the sensor lengths can be customized for your application.  We have developed custom probes and assemblies for some OEM Customers under Private Label brands.

Standard Sensor assembly: 3” diameter and approximately 20” long.

Part Number is EXT

e.g. WLC-5000-110-EXT-50  Is a 5000 Controller with an external static pipe sensor and a 50 ft wire lead on the sensor.

All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

We do make 2-1/2″ Vanstone flange sensors that are direct replacements for Evapco Cooling tower level controls (see this page for the technical details).  We can use any size vanstone flange to build a sensor into without any issues.  Let us know what you need for your application and we can help you get the right parts.  You can use this Sensor Appendix to get the correct length sensor tips needed.

PART NUMBERS for Sensor Tip Extensions

EXT3FT is a 3 ft extension kit with both ends threaded (this allows for other rods to be added)

EXT4FT is a 4 ft extension kit with both ends threaded (this allows for other rods to be added)

EXT5FT is a 5ft extension kit with both ends threaded (this allows for other rods to be added)

AXT3FT is a 3 ft extension kit with one ends threaded (these are the finished ends)

AXT4FT is a 4 ft extension kit with one ends threaded (these are the finished ends)

AXT5FT is a 5ft extension kit with one ends threaded (these are the finished ends)

All the Sensors we produce are Intrinsically Safe.

All WaterLine Controls WLC models can be fitted with a secondary PCB to operate two different sensor probe assemblies.  Now two probes can be mounted into two different environments provided there is an equalization line between them.  The controller can operate the same device(s) and will need a properly valved system so it can share either the same Fill valve or pump when it decides to operate.  The sensor are which ever style you choose.  The switch is done with a single switch located on the WaterLine Controls panel. No other parts are needed.

Standard Sensor assembly: 3” diameter and approximately 20” long.

Part Number is: Dual

e.g. WLC-5000-110-DUAL-50/50  Is a 5000 Controller with a dual static pipe and sensor and a 50 ft wire lead on each of the sensors. Includes the controls and installation set-up for both sensors and two sensors.

All the Sensors we produce are Intrinsically Safe.  Print the PDF below and submit it with your request.

This is the standard sensor that comes with every kit.  For most applications we typically use a 3″ this Sensor head which fits into any 3″ Slip Style fitting.  Regardless of which controls are used this sensor will hold all the sensor tips for all the models.  The sensor tip lengths are standard lengths but can be modified as needed for your application by submitting this Sensor Appendix.  We make custom lengths and develop part numbers for some OEMs under Private Labels.

Standard Sensor assembly: 3” diameter and approximately 20” long.

Part Number is STD

e.g. WLC-5000-110-EXT-50  Is a 5000 Controller with an external static pipe sensor and a 50 ft wire lead on the sensor.

These are low cost controls for any Float Switch operation.  This control comes in four different configurations: Single Float pump up or pump down, Two float pump up or pump down, single float pump up or down with a second float for a low alarm or high alarm and a pump up or down using two floats with a high or low alarm.

At this point we do not supply the float switches.  We are supply these controls so the voltage in the water or wet area meets the UL requirements not to exceed 24VAC.  These will always operate less the 24VAC through the float switches.  The enclosure is a NEMA6R and ideal for wet applications.  Ask your contractor how he plans to operate the floats so you know he is using some sort of low voltage system.  While we prefer the low voltage electronic sensing system we developed we realize that it may not always fit into the budget and has more features and functions than are needed for your application.

WLC-6000 – Fill w/ High & Low Alarms and a Low-Low Basin Heater Cut-off – Electronic Water Level Control | Complete Kit Includes Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High & Low Alarm and Low-Low Basin Heater Cut-off| FOUR-CONTACT POINT SYSTEM | Custom Sensors lengths and wire lengths available upon request | 10-wire Dry contacts to BAS for measuring Fill “ON” time, High Water Alarm and fault conditions.

PUMP DOWN OR SINGLE DRAIN WITH HIGH LEVEL SET POINT – WITH INTERNAL DIAGNOSTIC TEST SYSTEM – WaterLine Controls™ Model WLC-8000.

DUAL PUMP DOWN SYSTEM OR DUAL DRAIN WITH HIGH LEVEL SET POINT – WITH INTERNAL DIAGNOSTIC TEST SYSTEM – WaterLine Controls™ Model WLC-9000.

CheckPoint can be used in place of any Ultrasound Level Indicator, especially in water where there can sometimes be technical issues with the Ultrasound technology. CheckPoint easily integrates into any Building Automation System (BMS) using 0-20mA input as a function of level in the environment. CheckPoint can be made in any length needed for your application. CheckPoint is the latest development from WaterLine Controls. It is a digital Liquid Level Indicator, Water Level Indicator and Water Level Indicator For Tank level indicators. It is not intended to be a level controller.  It’s design and technology is designed to provide a level indication inside and environment.  It is plus or minus 5%-10% accurate.

WLC-6100T – Fill w/ High & Low Alarms and a Low-Low Basin Heater Cut-off and Basin Heater Controls – Electronic Water Level Control | Complete Kit Includes Level Sensors & Temperature Sensor With 50 ft. Sensor Wire, Controller, and Mounting Assembly | Fill w/ High & Low Alarm and Low-Low Basin Heater Cut-off & Heater Control| FOUR-CONTACT POINT SYSTEM WITH ONE TEMPERATURE SENSOR | Custom Sensors lengths and wire lengths available upon request | 10-wire Dry contacts to BAS for measuring Fill “ON” time, High Water Alarm, Low Water Alarm, Heater “ON” and fault conditions.

The temperature probe is built into the water level sensor and is to be mounted below the minimum water level of the tank (see the accompanying figure). It is also to be mounted at least 24 inches from the tank heater.
